Lenovo Legion 5 16IAX10 83NX0000US 16" Gaming Notebook - WQXGA - 240 Hz - Intel Core Ultra 9 275HX - 32 GB - 1 TB SSD - English Keyboard - Storm Gray
Intel HM870 Chip - 2560 x 1600 - Windows 11 Home - NVIDIA with 8 GB - In-plane Switching (IPS) Technology - Front Camera/Webcam - IEEE 802.11be Wireless LAN Standard - Wi-Fi 7
5 Series Laptops The intersection of minimalism and raw power
Own the room and the leaderboard with Legion 5 series gaming laptops. Designed with a plethora of high-performance options, while keeping a low profile with clean, minimalist looks that complement your lifestyle.
Package Contents
Legion 5 16IAX10 83NX0000US
Standard Battery
Power Adapter
Brand: Lenovo
Manufacturer part #: 83NX0000US
Specifications
General Information
Manufacturer Part Number: 83NX0000US
Product Type: Gaming Notebook
Technical Information
AI-powered: Yes
Processor
Processor Manufacturer: Intel
Processor Type: Core Ultra 9
Processor Model: 275HX
Processor Series: Series 2
Processor Core: Tetracosa-core (24 Core)
Processor Threads: 24
Maximum Turbo Speed: 5.40 GHz
NPU Manufacturer: Intel
NPU Name: AI Boost
NPU Performance: 13 TOPS
Chipset
Chipset Manufacturer: Intel
Chipset Model: HM870
Memory
Standard Memory: 32 GB
Maximum Supported System Memory: 32 GB
System Memory Technology: DDR5 SDRAM
System Memory Speed: 5600 MHz
System Memory Form Factor: SODIMM
Installed Slot Memory: 32 GB
Installed Slot Memory Configuration: 2 x 16GB
Total Number of Memory Slots: 2
Number of Occupied Memory Slots: 2
Number of Free Memory Slots: 0
Storage
Drive Type: SSD
Total Solid State Drive Capacity: 1 TB
SSD Form Factor: M.2
Display & Graphics
Screen Size: 16"
Display Screen Technology: In-plane Switching (IPS) Technology
Standard Refresh Rate: 240 Hz
Screen Mode: WQXGA
Screen Resolution: 2560 x 1600
Brightness: 500 Nit
Color Gamut: 100% DCI-P3
Touchscreen: No
Graphics Controller Manufacturer: NVIDIA
Graphics Controller Model: GeForce RTX 5060
Graphics Memory Capacity: 8 GB
Graphics Memory Technology: GDDR7
Graphics Memory Accessibility: Dedicated
AI GPU: Yes
AI TOPS (GPU): 572
Network & Communication
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11be
Wi-Fi Generation: Wi-Fi 7
Wimax: No
Ethernet Technology: Gigabit Ethernet
Bluetooth: Yes
WWAN Supported: No
Built-in Devices
Front Camera/Webcam: Yes
Front Camera/Webcam Resolution: 5 Megapixel
Finger Print Reader: No
Speaker Power Details: 2 x 2W
Sound Mode: Stereo
Interfaces/Ports
HDMI: Yes
Total Number of USB Ports: 4
Number of USB 3.2 Gen 1 Type-A Ports: 2
Number of USB 3.2 Gen 2 Type-A Ports: 1
Number of USB 3.2 Gen 2 Type-C Ports: 1
Number Of Ethernet Ports: 1
Network (RJ-45): Yes
Number of Thunderbolt 4 Ports: 1
Docking Capability: USB-C Thunderbolt 4
Operating System
Operating System Platform: Windows
Operating System: Windows 11 Home
Operating System Language: English
Input Devices
Keyboard Backlight: Yes
Keyboard Localization: English
Power Description
Power Plug Type: 3 pin
Included Charger Power: 245 W
USB Power Delivery Support: Yes
Physical Characteristics
Color Family: Gray
Product Color: Storm Gray
Height: 1.02"
Width: 14.3"
Depth: 10.6"
Weight (Approximate): 5.40 lb
Miscellaneous
Application/Usage: Gaming
Charger Included: Yes
Energy Star: Yes
Energy Efficiency Certification: ENERGY STAR 8.0
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 1 Year
